Disk harrow DANA BDP 3.2×2

Price request

The trailing two-row disk harrow DANA BDP-3.2×2 is designed for resource-saving preplanting cultivation and main tillage to a depth of 8 to 15 cm for cereals, industrial and forage crops, weed destruction, shredding crop residues, rejuvenating meadows and pastures.

It can be used in any agroclimatic zone, on all types of soil, except for stony soils and soils littered with flagstone.

Technical Parameters

Производительность за 1 час основного времени (га/ч)	up to 3,2
Operating speed, km/h	up to 10
Cut width, m	3,2±0,12
Constructive machine weight, kg	1842
Tilling depth, cm	up to 12
Overall dimensions (in operative position), mm
Length	5265±160
Width	3366±100
Height	1150±35
Disc diameter, mm	560
Press wheel diameter, mm	435
Number of tools, pcs	24
каток	1
Disk approach angle, deg.	0° — 30°
Spacing, mm
between discs in a row	250
between disc rows	950
Service life, years	8

Soil cultivation quality indicators

Soil surface ridgeness, not more than (cm)	3
Soil crumbling, not more than (lump size not more than 25 mm) (%)	90
Shredding crop residues (%)	60
Burial of vegetable and crop residues (%)	90

Compatibility

90 hp.:

DT-75, MTZ 892.2

Options

Attention!

The quality of cultivation is ensured on soils with specific resistance up to 0.09 MPa (0.9 kg/cm²), hardness up to 3,0 MPa (30 kg/cm²) and maximum humidity up to 25%.
